Hydraulic Shop Press Machine Manufacturer

TPS Series Hydraulic Press can assemble, disassemble, straightening, calendering, pressing, stretching, bending and punching of machine parts.  Each hydraulic press from Tsinfa Cnc equipment combines an industry-leading design with a thick, fully-welded steel plate frame. We build every hydraulic press to provide fine control and to save you time and effort—throughout many years of productivity.

Ranging from 10 to 10000 tons in capacity, our hydraulic presses will handle all the force you can throw at them. Choose a hydraulic press (for added power) or a pneumatic shop press (air-powered, typically with lighter capacities)  or hand operated h-frame shop press.

We can customize according to your request, for example, enlarge the workbench, let the worktable move, add two cylinders and so on.

A Tsinfa hydraulic workshop press includes, among other features:

  • Actually realize one machine to use more.
  • This series uses the Italian cnk and the CBZ oil pump two pumps to combine the oil, compared with the traditional hydraulic machine energy saving more than 60%, the efficiency increases 2-3 times.
  • Has the small volume, the pressure is high, the structure is simple, the weight is light.
  • Worktable can move up and down, greatly expanding the machine opening and closing height, more convenient to use.

Questions? Give us a call at +86-135-6111-0690, and talk to one of our expert reps. You can also fill out our contact form.

CAPAClTY(ton): 20/30/50/63/100
PRESSURE (MPa): 25/31.5
TRAVEL ( mm): 300/400
TABLE SIZE ( mm ): 400×300 400×600 400×700 500 x 800

Supply Ability:      200 Set/Sets per Month
Port:                       Qingdao/Shanghai

CAPACITY(ton): 20 40 63 100 150 200
PRESSURE(MPa): 25 25 25 30 30 30
TRAVEL(mm): 400 400 500 500 600 600
TABLE SIZE(mm): 360 x 400 360 x 400 400×800 500×1000 600×1200 800×1200

Supply Ability:      200 Set/Sets per Month
Port:                       Qingdao/Shanghai

CAPACITY(ton): 10 20 30 40 50
PRESSURE (MPa): 20 50 50 60 60
TRAVEL (mm): 180+450 2+450 200+450 250+450 250+450
TABLE SIZE(mm): 200 x 300 200 x 300 300×400 360 x 500 360 x 680

Supply Ability:      200 Set/Sets per Month
Port:                       Qingdao/Shanghai

CAPACITY(ton): 100 150 200 250 315 500
PRESSURE(MPa): 31.5 31.5 31.5 31.5 32 32
TRAVEL(mm): 300 300 300 300 400 500
TABLE SIZE(mm): 860*560 870*670 970*700 1090*800 1090*800 1440*1000
630*560 670*645 700*700 800*800 800*800 1000*1000

Supply Ability:      200 Set/Sets per Month
Port:                       Qingdao/Shanghai

CAPACITY(ton): 200 300 400 500 630
PRESSURE (MPa): 31.5 31.5 31.5 31.5 31.5
TRAVEL (mm): 300+405 300+405 300+405 300+405 400+405
TABLE SIZE(mm): 980 x 500 700×1200 800×1200 900×1200 1000×1200

Supply Ability:      200 Set/Sets per Month
Port:                       Qingdao/Shanghai

CAPACITY(ton): 20 40 63 100 150 200
PRESSURE(MPa): 25 25 25 30 30 30
TRAVEL(mm): 400 400 500 500 600 600
TABLE SIZE(mm): 360 x 400 360 x 400 400×800 500×1000 600×1200 800×1200

Supply Ability:      200 Set/Sets per Month
Port:                       Qingdao/Shanghai
